Full Automatic Fabric Spreading Machine with Conveyor Band

Full Automatic Fabric Spreading Machine with Conveyor Band

General Specifications:

  • Conveyor Band fabric feeder with Automatic tension control to enable adjustment of relaxation or tightness
  • Easy fabric roll loading with moving cradle design
  • Automatic fabric spreading with cutter tool
  • zig zag fabric spreading without cutting
  • Ability to use fabric cutter with zig zag spreading
  • Optical edge alignment with photcell sensors
  • Automatically adjustable spreading height according to fabric thickness.
  • Secure Operator platform
  • Automatic tension control
  • Ability to re-wind fabric
  • Ability to specify marker length and ply count.
  • Precise length control with encoder system
  • Easy to use LCD touch screen
  • Ability to be used on more than one table with transfer table
  • Speed control and change while spreading and without spreading



Technical Specifications:

  • Standard roll diameter: 50 cm
  • Standard roll weight: 160 kg
  • Standard spreading height: 25 cm
  • Standard spreading width: 160/180/200/220/240 cm
  • Gross Weight of the machine: 350 kg
  • Spreading speed: 105 meter/minute
  • Power Consumption: 220-240-v ac 50 hz 3,5 kw



Additional Tolls:

  • Zig-Zag spreading tool
  • Tube Fabric spreading tool
  • Front back nipper
  • Fabric Expanding and Swinging Unit
  • Spreading from folded fabric stack tool
